What Is a Screw Thread Machine For

The working principle

1. Steel reinforcement clamping structure:

The clamping of steel bar is completed by the sliding self-centering mode of clamping clamp body driven by rotation of screw thread.

2. Thread head processing:

The steel bar is clamped, the rib is stripped and the thread is rotated and fed in axial direction.The rotation of the rib-stripping spinning head is completed by the main motor through the reducer at a speed of 50 revolutions per minute.The feeding process is completed by the operator to push the handle through the gear and rack to drive the reducer and strip the ribbed roller head along the sliding bar.

3. Spinning wheel:

The thread rolling wheel consists of three parts, which can be installed interchangeably.

4. Advance and retreat:

Open the main motor button, the motor drives the reducer and the rib-stripping thread rolling head to rotate, the operator pulls the handle to feed, and when the thread processing is completed, the stroke switch contact plate presses the stroke switch button, and after the delay, it reverses back to the starting position and stops automatically.
