Starting method of internal combustion gasoline rock drill

The internal combustion gasoline rock drill is a tool used to directly mine stone. It drills blastholes in the rock formations so that explosives can be put in to blast the rocks, thereby completing stone mining or other stonework projects. In addition, the rock drill can also be used as a breaker to break hard layers such as concrete. Then let the editor come to the eldest sister to introduce how the internal combustion rock drill is started!

(1) When the internal combustion gasoline rock drill engine is pneumatic, the starting rope should be gently pulled after the ratchet mechanism is engaged. Pull the starting rope in the correct direction, and don't use too much force to prevent the starting rope from pulling out. (2) When the rock drill is started with the drill pipe installed, the handle clutch of the internal combustion rock drill is not allowed to turn to the rotating position. (3) Always pay attention to whether the fiber rod hole is blocked, and the machine stalls. (4) In order to protect the slewing mechanism, the machine should not be overloaded. (5) Because the internal combustion rock drill uses gasoline as fuel, the exhaust gas will pollute the air. Therefore, under normal circumstances, it is only allowed to work in the open.

The internal combustion gasoline rock drill is a new type of rock drilling machine powered by a low-power internal combustion engine, which is suitable for field operations without power supply and air compressor. According to work needs, in addition to drilling operations, internal combustion type rock drills are generally equipped with more than ten tools (such as grinding wheels, picks, shovels, shovel, etc.) for crushing, shoveling, digging, splitting, tamping, etc. .

The internal combustion gasoline rock drill is a rock drill powered by fuel combustion. It is a hand-held rock drill tool composed of a small gasoline engine, a compressor, and a rock drill. Mainly used for drilling down, horizontal and upward blast holes less than 45°, replacing a few parts, can be changed to a crusher or tamping machine, used for various shoveling, crushing, digging, splitting and tamping work . Because the machine has its own power and self-produced compressed air to blow the blasthole, it is especially suitable for high mountains, areas without power supply, and compressed air equipment, and temporary projects with high mobility. It is widely used in open-pit mining, excavation of frozen soil, road construction, cable laying and water conservancy construction, etc.
